Adjustable Mold Block Wire Winder Electric Coil Winding Machine 100rpm

Brand Name : STT

Model Number : MW1200

Place of Origin : China

MOQ : 1 set

Price : negotiable

Payment Terms : T/T, L/C

Supply Ability : 100 sets per year

Delivery Time : 20 days

Packaging Details : seaworthy packing

Name : motor coil winding machine

Application : winding motor coil

Rotating diameter : 1200mm

Machine color : optinal

Rotating power : 3kw

Winding speed : 0 ~ 100rpm

Machine height : 1400mm

Warranty : 12 months

Contact Now

Adjustable Mold Block Wire Winder Electric Motor Coil Winding Machine

Description of motor coil winding machine MW1200

Electric motor coil winding machine MW1200 is mainly used to wind motor coils and other similar products. The motor coil winding machine is equipped with an adjustable movable mold, which can be used to mount a wire mould on the upper and lower movable blocks with long screws respectively. By turning a screw rods of the movable die, the height of the wire mould can be adjusted with range from 150mm to 1200mm, therefore the motor coil winding machine can be used to wind different size of the motor coil.

Quick details of motor coil winding machine MW1200

3KW motor providing strong pulling force
1400mm machine height
Winding speed 0 ~ 100rpm
Smooth running
Adjustable blocks
Simply structure

Main Parameters of motor coil winding machine MW1200

Typical standard specifications of motor coil winding machine MW1200 are shown below, however, the motor coil winding machine can also be manufactured as requested.

Machine Height:	1400mm
Mold Expansible Range:	150 ~ 1200mm
Maximum Winding Speed:	0 ~ 100 rpm
Counting Range:	0-9999.9
Max. Loading Capacity:	500KG
Winding Motor Power:	3KW
Machine Colour:	customized
Machine Dimension(LxWxH):	900x700x1400mm

Adjustable Mold Block Wire Winder Electric Coil Winding Machine 100rpm

Fig 1: Motor coil winding machine MW1200's full view

Adjustable Mold Block Wire Winder Electric Coil Winding Machine 100rpm

Fig 2: Motor coil winding machine MW1200's matched coil former

Adjustable Mold Block Wire Winder Electric Coil Winding Machine 100rpm
